Sheng Yeh Electronics Co., Ltd. - Electronic Circuit Design Products

Modular Collaborative Palletizing Workstation

CP Series Modular Collaborative Palletizing Workstation

Customized AMR — Logistics Lifting and Transfer AG

Customized AMR — Logistics Lifting and Transfer AGV

Customized AMR — Logistics Roller AGV

Customized AMR — Logistics Roller AGV

Standard Composite Robot — MM500

Standard Composite Robot — MM500

Standard Composite Robot — MM650

Standard Composite Robot — MM650

Single-Arm Coffee Robot

Single-Arm Coffee Robot

Selectable High-End Commercial Coffee Machine Model
Equipped with: Countertop ice maker, automatic cup dispenser,
    water purifier
Product Dimensions: 1000 × 1000 × 1600 mm
Product Weight: Approx. 200 kg
Footprint: Approx. 1 m²
Rated Power: 2 kW (Peak: 3 kW)
Capabilities:
    Supports production of 10+ beverage types
    Automatic cup dispensing
    Production efficiency: ~50 cups/hour
    Quick refill cycle: 5 minutes per refill, enough for 40 cups
Convenient Maintenance:
    One-touch power on/off
    One-touch cleaning
    One-touch fault resolution
    Remote monitoring and alerts for material levels



Dual-Arm Master Coffee Machine Pro

Dual-Arm Master Coffee Machine Pro

Swiss Imported High-End Commercial Coffee Machine: EVERSYS
Equipped with: Countertop ice maker, automatic cup dispenser,
    water purifier
Product Dimensions: 1180 × 1180 × 1600 mm
Product Weight: Approx. 400 kg
Footprint: Approx. 1.5 m²
Rated Power: 4 kW (Peak: 5 kW)
Capabilities:
    Supports production of 10+ beverage types
    Automatic cup dispensing
    Production efficiency: ~50 cups/hour
    Quick refill cycle: 5 minutes per refill, enough for 40 cups
Convenient Maintenance:
    One-touch power on/off
    One-touch cleaning
    One-touch fault resolution
    Remote monitoring and alerts for material levels


Q-Bot

Intelligent Commercial Cleaning Robot

Sweeping + Dust Collection + Vacuuming + Mopping
Product Model: Q-Bot
Dimensions: 663 * 568 * 682 mm
Net Weight: 60 kg
Sweeping Width: 500 mm
Scrubbing Width: 400 mm
Tank Capacity: Clean Water Tank 15L / Recovery Tank 17L
Charging Time: ＜ 4h
Battery Life: Max 9h
Cleaning Efficiency: 700 - 1000 m²/h
Operation Noise: ＜ 70 dB
Max Movement Speed: Max 1.2 m/s
Positioning Mode: Dual-mode Positioning (Marker positioning up to 8m height / LiDAR positioning with no height limit)

Cool-chan

Seamless Navigation During Peak Hours Delivery Robot

Seamless Mobility + Agile Maneuverability
Product Model: Cool-chan (酷醬)
Dimensions: 485 * 593 * 1277 mm
Net Weight: 59 kg
Minimum Aisle Width: 900 mm
Tray Size: 433 * 502 mm
Single Tray Capacity: 15 kg
Total Payload: 35 kg
Battery Life: Approx. 7 ~ 24 hr
Operating Speed: 0.5 ~ 1.2 m/s (Adjustable)
Charging Time: 4 hr
Battery Capacity: 21 Ah
Positioning Mode: Dual-mode Positioning (Marker positioning up to 8m height / LiDAR positioning with no height limit)

High-Speed

Disinfection Robot

360° Spray Disinfection + UV Disinfection
Model: Extreme Speed
Dimensions: 544*538*1290mm
Weight: 60kg
Passage Width: 700mm
Disinfectant Capacity: 15L (Hydrogen Peroxide, Hypochlorous Acid, Chlorine Dioxide, etc.)
UV Irradiation Distance: 3m
UV Intensity at 1m: 188μW/cm² , UV-C (254nm)
Battery Life: Approx. 6hr
Travel Speed: 0.5~1.2m/s (Adjustable)
Charging Time: 8hr (Supports Auto-Recharge)
Battery Capacity: 51.2Ah
Positioning Method: Laser Positioning

Super-man

Building Delivery Robot

Auto Gate & Elevator Operation + Spatial Pressure Human Detection
Model: Superman
Dimensions: 539*515*1050mm
Weight: 55kg
Compartment Size: Single 410*219*286mm / Double 410*438*286mm
Load per Tier: 15kg
Total Payload: 30kg
Battery Life: Approx. 12hr
Travel Speed: 0.5~1.5m/s (Adjustable)
Charging Time: 4.5hr
Battery Capacity: 15.6Ah
Positioning Method: Laser Positioning

Precision-Delivery Ⅱ

Intelligent Food Delivery Robot

Classic Reimagined + Stable & Fast Operation
Model: Precision Delivery II
Dimensions: 580*535*1290mm
Weight: 37kg
Passage Width: 900mm
Tray Size: 432*500mm
Load per Tier: 10kg
Total Payload: 40kg
Battery Life: Approx. 10~24hr
Travel Speed: 0.5~1.2m/s (Adjustable)
Charging Time: 3hr
Battery Capacity: 21Ah

Lobot

Greeting & Delivery Robot

LED Digital Signage + Greeting & Attraction + Simple Delivery
Model: LeBao
Dimensions: 460*440*1120mm
Weight: 35kg
Passage Width: 550mm
Tray Size: 352*340mm
Load per Tier: 10kg
Total Payload: 30kg
Battery Life: Approx. 7~24hr
Travel Speed: 0.5~1.2m/s (Adjustable)
Charging Time: 4hr
Battery Capacity: 25.6Ah
Positioning Method: Dual Mode Positioning - Marker Positioning (Max height 8m) / Laser Positioning (Unlimited height)

Happy

Call-and-Notify Delivery Robot

High Payload + IPX5 Waterproof Design
Model: HeiPi
Dimensions: 541*531*1226mm
Weight: 60kg
Passage Width: 800mm
Tray Size: 355*453mm
Load per Tier: 15kg
Total Payload: 60kg
Battery Life: Approx. 10~24hr
Travel Speed: 0.5~1.2m/s (Adjustable)
Charging Time: 4.5hr
Battery Capacity: 25.6Ah
Positioning Method: Dual Mode Positioning - Marker Positioning (Max height 8m) / Laser Positioning (Unlimited height)

Ami

Premium Food Delivery Robot

Human Interaction + Intelligent Structure
Model: Amy
Dimensions: 565*537*1290mm
Weight: 57kg
Passage Width: 800mm
Tray Size: 410*500mm
Load per Tier: 10kg
Total Payload: 40kg
Battery Life: Approx. 12~24hr
Travel Speed: 0.5~1.2m/s (Adjustable)
Charging Time: 4.5hr
Battery Capacity: 25.6Ah
Positioning Method: Dual Mode Positioning - Marker Positioning (Max height 8m) / Laser Positioning (Unlimited height)

Digital Temperature Display

Voltage: DC 5V
Dimensions: 50*50*30mm
Display Panel: OLED Display
Cable: Micro B (PC Connectable)
Temperature Range: -40℃~+150℃
Control panel with built-in temperature sensor
User-settable minimum/maximum adjustable temperature
All specifications above can be customized. This is a custom product; please contact us for inquiries.

Scheduled Temperature-Controlled Heater

Voltage:AC110V
Load Output Voltage: AC24V
Temperature Control: 40~150℃
Timer Control: 1min~60min
Controls 12 sets of output heating elements

Neural Stimulation Waveform Generation(Low Frequency)

Voltage Range :3~5V
Stimulation Range :
0-30 mA, minimum 80 V compliance 80 V (80 V- 10%) tested at 10 K load
100-10 KOhms (0-3 mA): Compliance 10 V (3.5-30 mA): Compliance 60 V
Stimulation Output Accuracy:
Digital control range – Depends on adjustment increments of 0.01, 0.05, 0.1, .5 and 1.0 mA
, ±0.01 mA within stimulation range (or ±10% of reading at 1K load)

IoT Smart Pet Feeder

Pet Appliance Market integrating mobile apps via IoT
Product Design Company

Custom Automotive Lighting

Heavy Motorcycle Tail Light for European and American Aftermarkets
Product Design Company
